Stream Type allows enable/disable the audio streaming from the cameras (if the camera does not have
audio capabilities, then the Stream Type will only have Video option)
Resolution allows setting of the recording resolution
Bitrate Type allows the NVR to save HDD space when set to Variable (Available choses: Variable
and Constant)
Video Quality adjusts picture clarity (medium setting (3 green squares) is recommended. Medium
setting is the balance between good picture and saving HDD space).
Frame Rate allows setting of the recording frame rate (12-15 fps is recommended to save HDD space
and not to have a “choppy” image)
Max Bitrate Mode allows choosing between preset bitrate values and customizing the values
(General setting is recommended)
Max Bitrate (KBPS) is the chosen bitrate for streaming the video
Max Bitrate Recommended is the NVR’s recommended bitrate according to the parameters set
above.
Record Audio allows turning the audio recording on or off (this option is only available if the camera
has a microphone connected to it, or only the analog channels 1-4 on the hybrid NVR).
Video Stream allows changing the recording stream between Main Stream and Sub Stream (this step
requires a restart).
Please refer to the table below for recommended recording parameters
Resolution
Video Quality
Frame Rate (FPS)
Bitrate (KBPS)
320x240 (QVGA)
Medium (3 squares)
12-15
207
352x240 (CIF)
Medium (3 squares)
12-15
384
640x480 (VGA)
Medium (3 squares)
12-15
768
704x480 (4CIF)
Medium (3 squares)
12-15
1024
1280x720 (720P)
Medium (3 squares)
12-15
2048
1280x960 (960P)
Medium (3 squares)
12-15
2048
1600x1200 (2MP)
Medium (3 squares)
12-15
2560
1920x1080 (1080P)
Medium (3 squares)
12-15
3072
2048x1536 (3MP)
Medium (3 squares)
12-15
3072
2560x1920 (5MP)
Medium (3 squares)
8
4096
SETTING UP RECORDING

HIKVISION DS-7608NI-E2/8P Specifications

General

Display modes	Live view
Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Alarm input channels	4
Video input channels	8 channels
Alarm output channels	1
Resolution at capture speed	1920x1080@60fps
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
Power consumption (typical)	10 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Number of HDDs supported	2
Total installed storage capacity	0 GB

Weight and Dimensions

Depth	290 mm
Width	445 mm
Height	45 mm
Weight	1000 g
