HIKVISION DS-7608NI-E2/8P Quick Start Guide

www.hikvision.com/en/us
Last step in the recording setup is setting up the Sub Stream.
The Sub Stream is used for streaming on mobile devices, as well as displaying multiple cameras on
the local output
SETTING UP RECORDING
Record
Quality
Select
Sub
Stream
Unlike Main Stream,
Sub Stream can only go up to 4CIF
Select
Camera
 Please note: If the upload speed is not sufficient, consider lowering the frame rate/bitrate/resolution
for more fluent mobile app viewing.

HIKVISION DS-7608NI-E2/8P Specifications

General

Display modes	Live view
Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Alarm input channels	4
Video input channels	8 channels
Alarm output channels	1
Resolution at capture speed	1920x1080@60fps
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
Power consumption (typical)	10 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Number of HDDs supported	2
Total installed storage capacity	0 GB

Weight and Dimensions

Depth	290 mm
Width	445 mm
Height	45 mm
Weight	1000 g
