HIKVISION DS-9104HFI-S User Manual

Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
Alarm in
16
Alarm out
4
Others
Power supply
100~240VAC, 6.3A, 50~60Hz
Consumption
(without
hard disk)
28W
Working
temperature
-10℃~+55℃
Working
humidity
10%~90%
Chassis
19” standard 2U chassis
Size(mm)
450mm(D)×450mm(W)×95mm(H)
Weight
(without
hard disk)
≤8Kg
Model
DS-9100HDI-S
Video/Audio
input
Video compression
H.264
Video input
4/8/16-ch, BNC(1.0Vp-p, 75Ω)
PAL/NTSC adaptive
Audio compression
OggVorbis
Audio input
4/8/16-ch, BNC(2Vp-p, 1kΩ)
Voice talk input
2-ch, BNC(2Vp-p, 1kΩ)
Video/Audio
output
Preview resolution
PAL: 704×576 NTSC: 704×480
VGA output
1, resolution:
1024×768/60Hz
1024×768/70Hz
1280×1024/60Hz
Playback resolution
4CIF/2CIF/CIF/QCIF
Video output
2-ch, BNC (1.0Vp-p, 75Ω)
Frame rate
4CIF: 12(P)/15(N)
2CIF: 25(P)/30(N)
Bit rate
32Kbps~2048Kbps, or user defined,
Max 6144Kbps
Audio output
2-ch, BNC (linear, 600Ω)
Audio Bit rate
16kbps
Synchronous
Playback
4/8/16-ch
Hard disk
Interface type
8, SATA interface
Capacity
Each supports more than 2TB capacity
External
interface
Network interface
1, RJ45 10M/100M/1000M adaptive
Ethernet
Serial interface
1 RS-232 interface (for parameters
configuration, maintenance,
transparent channel);

HIKVISION DS-9104HFI-S Specifications

General

Brand	HIKVISION
Model	DS-9104HFI-S
Category	DVR
Language	English
