Network Video Recorder Quick Start Guide
19
3.2.2 Shutdown
Steps:
1. Enter the Shutdown menu.
Menu > Shutdown
Figure 3. 2 Shutdown
2. Select the Shutdown button.
3. Click the Yes button.
3.3 Activating Your Device
Purpose:
For the first-time access, you need to activate the device by setting an admin password. No operation is allowed
before activation. You can also activate the device via Web Browser, SADP or client software.
Steps:
1. Input the same password in the text field of Create New Password and Confirm New Password.
Figure 3. 3 Set Admin Password
STRONG PASSWORD RECOMMENDEDWe highly recommend you create a strong password
of your own choosing (Using a minimum of 8 characters, including at least three of the following
categories: upper case letters, lower case letters, numbers, and special characters.) in order to increase
the security of your product. And we recommend you reset your password regularly, especially in the high
security system, resetting the password monthly or weekly can better protect your product.
2. Click OK to save the password and activate the device.

Other manuals for HIKVISION DS-96128NI-I24

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-96128NI-I24 and is the answer not in the manual?

HIKVISION DS-96128NI-I24 Specifications

General IconGeneral
Audio system2-way
Input bandwidth576 Mbit/s
Output bandwidth512 Mbit/s
Maximum resolution4096 x 2160 pixels
Alarm input channels16
Video input channels128 channels
Alarm output channels8
Supported resolutions4096 x 2160, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video formats supportedH.264, H.264+, H.265, H.265+, M-JPEG, MPEG4
Number of simultaneously playbacked channels16 channels
Audio RCA inputs1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports4
Supported network protocolsIPv6, HTTPS, UPnP, SNMP, NTP, SADP, SMTP, NFS, iSCSI, PPPoE, DDNS
Product colorBlack
Rack capacity4U
Rack mountingYes
RAID levels0, 1, 5, 10
HDD capacity- GB
HDD interfaceSATA
Maximum storage capacity10 TB
Number of HDDs installed0
Number of HDDs supported24
AC input voltage100 - 240 V
Power consumption (typical)14 W
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)10 - 90 %
Display typeLCD
Weight and Dimensions IconWeight and Dimensions
Depth528 mm
Width447 mm
Height172 mm
Weight23000 g
