HIKVISION DS-D5022FN00 User Manual

22-Inch & 24-Inch Monitor • User Manual
8
OSD parameters concern the display effect of OSD, such as position, transparency, and rotation.
OSD Settings
OSD Parameters
Parameter
Description
Horizontal
Ranges from 0 to 100.
Vertical
Ranges from 0 to 100.
Transparency
Off/Weak/Medium/Strong
OSD Time Out
Off/5 S/15 S/30 S/1 Min
OSD Rotation
Off/On
Keypad
Set as On by default. If set as Off, OSD can
be changed within 5 seconds. If there is no
operation with the 5 seconds, the system
will exit OSD and you can press any button
to see unlock prompt. You can follow the
prompt and hold Menu to unlock.
If OSD Rotation is enable, the OSD will rotate 270 degrees clockwise, and the point (0, 0) is at
the bottom-left corner.

HIKVISION DS-D5022FN00 Specifications

General

Brand	HIKVISION
Model	DS-D5022FN00
Category	Monitor
Language	English
