HIKVISION DS-K2600 Series User Manual

DS-K2600 Serial Access Controller
15
No.
DS-K2604
A1
Power
Supply of
E-Lock
GND
Grounding
A2
+12V
Power Supply of E-Lock Output
A3
Power
Supply of
Card Reader
GND
Grounding
A4
+12V
Power Supply of Card Reader Output
A5
Weigand
Card Reader
4
GND
Grounding
A6
W0
Weigand Card Reader Data Input Data0
A7
W1
Weigand Card Reader Data Input Data1
A8
BZ
Buzzer of Card Reader Control Output
A9
ERR
Cresset of Card Reader Control Output
(Invalid Card Output)
A10
OK
Cresset of Card Reader Control Output (Valid
Card Output)
A11
Weigand
Card Reader
3
GND
Grounding
A12
W0
Weigand Card Reader Data Input Data0
A13
W1
Weigand Card Reader Data Input Data1
A14
BZ
Buzzer of Card Reader Control Output
A15
ERR
Cresset of Card Reader Control Output
(Invalid Card Output)
A16
OK
Cresset of Card Reader Control Output (Valid
Card Output)
A17
Weigand
Card Reader
2
GND
Grounding
A18
W0
Weigand Card Reader Data Input Data0
A19
W1
Weigand Card Reader Data Input Data1
A20
BZ
Buzzer of Card Reader Control Output
A21
ERR
Cresset of Card Reader Control Output
(Invalid Card Output)
A22
OK
Cresset of Card Reader Control Output (Valid
Card Output)
