HIKVISION DS-K2800 Series Quick Start Guide

DS-K2800 Serial Access Controller
10
No.
DS-K2802
Output (Valid Card Output)
C9
ERR
Indicator of Card Reader Control
Output (Invalid Card Output)
C10
BZ
Card Reader Buzzer Control Output
C11
W1
Wiegand Head Read Data Input Data1
C12
W0
Wiegand Head Read Data Input Data0
C13
PWR
Card Reader Power Output
C14
GND
C15
Wiegand Card Reader 3
OK
Indicator of Card Reader Control
Output (Valid Card Output)
C16
ERR
Indicator of Card Reader Control
Output (Invalid Card Output)
C17
BZ
Card Reader Buzzer Control Output
C18
W1
Wiegand Head Read Data Input Data1
C19
W0
Wiegand Head Read Data Input Data0
C20
PWR
Card Reader Power Output
C21
GND
C22
Wiegand Card Reader 4
OK
Indicator of Card Reader Control
Output (Valid Card Output)
C23
ERR
Indicator of Card Reader Control
Output (Invalid Card Output)
C24
BZ
Card Reader Buzzer Control Output
C25
W1
Wiegand Head Read Data Input Data1
C26
W0
Wiegand Head Read Data Input Data0
C27
PWR
Card Reader Power Output
C28
GND
