Access Control Terminal·User Manual
85
Notes:
 The displayed card readers in the card reader afterward input field should be in
authentication order.
 Up to 64 controllers with anti-passing back function can be added.
 Up to 16 card readers afterward can be added for each card reader.
 It supports M1 card at present and the sector cannot be encrypted. For details
about sector encryption, refers to 7.4.8 M1 Card Encryption.
 Based on Network
Note: Authenticate the anti-passing back according to the entrance and exit information
on the card reader.
1) Select Based on Network as the anti-passing back mode in the drop-down list.
2) Select Route Anti-passing Back as the rule.
3) Select a server in the drop-down list for judging the anti-passing back.
4) (Optional) You can click Delete Anti-passing Back Record and select the card in the
pop-up window to delete the card swiping information in all devices.
The user should be start swiping card again from the first card reader.
5) In the Set Card Reader area, click the icon on the left of the card enrollment station
column to select the first card reader. The icon will turn to .
6) Click the card reader afterward input field to select the card readers afterward in the
pop-up window.
7) Check the checkbox in the Enable Anti-passing Back column to enable the anti-passing
back function.
Notes:
 The displayed card readers in the card reader afterward input field should be in
authentication order.
 Up to 64 controllers with anti-passing back function can be added.
 Up to 16 card readers afterward can be added for each card reader.
 Up to 5000 cards’ swiping records can be stored in the selected server.
Setting Entrance/Exit Anti-passing Back
Purpose:
You can set the entrance card reader and the exit card reader only for entering and exiting, without
setting the first card reader and the card readers afterwards.
Steps:
1. In the Cross-Controller Anti-passing Back tab, check the Enable Cross-Controller Anti-passing
Back checkbox to enable the function.
2. Set the anti-passing back parameters.
 Based on Card
Note: The system will judge the anti-passing back according to the entrance and exit
records on the card.
1) Select Based on Card as the anti-passing back mode in the drop-down list.
2) Select Entrance/Exit Anti-passing Back as the rule.

HIKVISION DS-K2802 Specifications

General

Product type	Access controller
Certification	CE, FCC
Compatibility	Wiegand
Mounting type	Wall
Product color	Black
Brand compatibility	Hikvision
Operating temperature (T-T)	-20 - 65 °C
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	285 mm
Width	237 mm
Height	69 mm
