HIKVISION DS-MH6171I-S

Network Portable IR Speed Dome Quick Start Guide
12
Hold Battery Container Between Figures
Figure 2-8 Uninstall Battery Container
Battery Container
Figure 2-9 Drag Battery Container
3. Insert the SD card into the SD card slot with the metallic surface of SD card facing
the other side of the battery container by the direction shown in Figure 2-10.
4. Insert the battery container into the cavity of the speed dome by the direction
shown in Figure 2-11.
SD Card Slot
SD Card
Figure 2-10 Insert SD Card
Battery Container
Figure 2-11 Install Battery Container
5. Press the four corners of the battery container until it is fixed.
Battery Container
Figure 2-12 Fix Battery Container
