HIKVISION DS-MH6171I-S

Network Portable IR Speed Dome Quick Start Guide
18
Hoop Mount
Adapter Mount
Figure 2-22 Assemble Hoop Mount and Adapter Mount
2. Install hoops to the hoop mount.
Hoop
Figure 2-23 Install Hoops
3. Fix the assembled hoop mount and adapter mount to the vertical pole.
