83
5.
Select to enable Alarm Strobe Flash, Alarm Buzzer, Lid Open When Disarmed, Arm/Disarm LED
Indicator, and Arm/Disarm Buzzer.
6. Set the Polling Rate.
7. Enable Enroll Wireless Sounder
8. Click OK.
Note
After the sounder is configured, you can click Maintenance → Device Status → Sounder Status
to view the sounder status.
Keypad
You can set the parameters of the keypad that is enrolled to the AX PRO.
Steps
1. Click Device → Keypad to enter the page.
2. Click to enter the Keypad Settings page.
3. Set the keypad name.
4. Enable the function of buzzer, silent panic alarm, silent medical alarm, and keypad button.
5. Enable the function of arming without password and active on entry delay.
6. Check the Enable check box of Back-light Off Time, and set the duration of light off.
7. Set the polling rate.
8. Select the keypad linked area.
To Next Page
