User Manual of Digital Video Recorder
107
Here we take the backup by motion detection as the example.
Backup by alarm input is supported by DS-7300 and DS-8100 series DVR.
2) Check the checkbox of cameras and set the search time.
3) Click Search button to enter the Search Result interface.
Figure 7. 8 Event Search for Backup
3. Select record files to export.
1) Select an alarm input in the list and click Quick Export button to enter Export interface.
2) Clicking Details button will take you to the interface with detailed information of all channels
triggered by the event.
Figure 7. 9 Result of Event Search
3) Click Details button to view detailed information of the record file, e.g. start time, end time, file size,
etc.
The size of the currently selected files is displayed in the lower-right corner of the window.
