User Manual of Digital V
ideo Recorder
93
Figure 6. 14
Vide
o Search by Tag
3.
Click
button to play back the file.
You can click the
Back
button to back to the search interfa
ce.
Pre-play and post-play can be configured.
Figure 6. 15
Interface of Playback
by Tag
Figure 6. 16
Toolbar of Playback by
Tag
