Figure 2-13 Install the Wall Mounting Bracket
3. Install the mounting base of the camera to the wall mounting
bracket and secure them with supplied screws.
Figure 2-14 Install the Mounting Base on the Wall Mounting Bracket
4. Repeat steps 5 to 8 of 2.2 Ceiling Mounting to complete the
installation.
Install Network Cable Waterproof Jacket
If the camera is installed outdoor, you should use the waterproof
accessory to waterproof the network cable. Otherwise the cable
might get wet or a short circuit occurs.
