HIKVISION iDS-2CD9396-AS

Network Traffic Camera • Quick Start Guide
8
Rear Panel Interface
Interface
Description
LAN1/LAN2
10/100/1000M Ethernet interface, connecting switch and
computer.
AIN
Audio iuput.
TF
TF card slot.
AOUT
Audio output.
PWR
Power indicator.
VIDEO OUT
Analog video output interface, supporting CVBS output.
RST
Reserved.
Ground.
RTG
RS-232 interface for debugging and temperature shield controll via
transparent channel.
D1~D3
RS-485 interface, for transferring RS-485 input information (such as
radar, vehicle detector, etc.).
SYNC
Synchronization input interface.
T1~T4
Input trigger interface.
F1~F6
Flash light trigger output interface.
USB
USB interface.
DC 12V
12 DC power input.
