1) Set Number of Lane and the width of each lane.
Note
The number of lanes is consistent with the total lanes in the applicaon mode sengs.
2) Set Scene Mode.
3) Set Vehicle Direcon.
Approaching
Direcon
The vehicles are driven towards the construcon posion of the camera.
Leaving Direcon
The vehicles are driven far away from the construcon posion of the camera.
Bidirecon
There are vehicles driven both towards and far away from the construcon posion of the
camera.
4) Set the construcon parameters.
Construcon Height
Set the construcon height of the radar according to construcon at the actual scene.
Horizontal
Deviaon
It is the horizontal posion deviaon between the radar detected lane and the actual lane.
You can set it in two ways.
●
Method 1: Move the detected lane in the diagram
lewards or rightwards to overlap it
with the actual lane to correct the
dierence.
●
Method 2: Enter the horizontal distance(m) from the radar installaon posion to the
middle line of the actual lane to correct the
dierence.
Angle Deviaon
It is the angle deviaon between the radar detected lane and the actual lane. Rotate the
angle of the detected lane in the diagram to overlap it with the actual lane to correct the
dierence.
5) Set Coordinate Calibraon and GPS Calibraon. Refer to Set Radar Calibraon for details.
4.
Set radar parameters.
Radar Wi-Fi
You can set radar parameters via Wi-Fi
aer enabling it.
Speed Detecon via Radar and Video
Check it to match detected speeds with detected objects in live view.
Frequency Band Conguraon
Set it to avoid interferences that caused by mulple radars in the same frequency band.
5.
Set the other parameters.
Display Track
