ﻧﻄﺎﻕﺗﺮﺩﺩﺷﺒﻜﺔWLAN
2,400ﻣﻴﺠﺎﻫﺮﺗﺰ…
2,483.5ﻣﻴﺠﺎﻫﺮﺗﺰ|
5,150ﻣﻴﺠﺎﻫﺮﺗﺰ…
5,350ﻣﻴﺠﺎﻫﺮﺗﺰ|
5,470ﻣﻴﺠﺎﻫﺮﺗﺰ…
5,835ﻣﻴﺠﺎﻫﺮﺗﺰ
ﺃﻗﺼﻰﻗﺪﺭﺓﺇﺭﺳﺎﻝﺻﺎﺩﺭﺓﻣﻦBluetooth
®
9.5ﺩﻳﺴﻴﺒﻞ/ﻣﻠﻠﻲﻭﺍﻁ
ﻧﻄﺎﻕﺗﺮﺩﺩﺧﺎﺻﻴﺔﺑﻠﻮﺗﻮﺙ
2,400ﻣﻴﺠﺎﻫﺮﺗﺰ…
2,483.5ﻣﻴﺠﺎﻫﺮﺗﺰ
4.2ﻗﻴﺎﺱﻣﺴﺎﻓﺔﺍﻟﻠﻴﺰﺭ
ﻃﻮﻝﺍﻟﻤﻮﺟﺔ
646ﻧﺎﻧﻮﻣﺘﺮ…674ﻧﺎﻧﻮﻣﺘﺮ
ﻟﻮﻥﺍﻟﻠﻴﺰﺭ
ﺣﻤﺮﺍء
ﻓﺌﺔﺍﻟﻠﻴﺰﺭﺣﺴﺐIEC 60825-1
2
ﻣﺘﻮﺳﻂﻗﺪﺭﺓﺍﻟﺨﺮﺝﺍﻷﻗﺼﻰ
>1ﻣﻠﻠﻲﻭﺍﻁ
ﻣﺪﺓﺍﻟﻨﺒﺾ
0.06ﻧﺎﻧﻮﺛﺎﻧﻴﺔ…2.5ﻧﺎﻧﻮﺛﺎﻧﻴﺔ
ﺍﻟﺘﺮﺩﺩﺍﻟﻨﺒﻀﻲ
3ﻣﻴﺠﺎﻫﺮﺗﺰ…102ﻣﻴﺠﺎﻫﺮﺗﺰ
ﺍﻧﺤﺮﺍﻑﺍﻟﺸﻌﺎﻉ
0.1ﻣﻠﻠﻲﺭﺍﺩﻳﺎﻥ…5.5ﻣﻠﻠﻲ
ﺭﺍﺩﻳﺎﻥ
4.3ﺩﻗﺔﺍﻟﻘﻴﺎﺳﺎﺕﻋﻨﺪﻗﻴﺎﺱﺍﻟﺰﻭﺍﻳﺎ)ISO 17123-3(
PLT 4002
2")0.6mgon(
PLT 4004
4")1.2mgon(
4.4ﺩﻗﺔﺍﻟﻘﻴﺎﺳﺎﺕﻋﻨﺪﻗﻴﺎﺱﺍﻟﻤﺴﺎﻓﺎﺕ)ISO 17123-4(
ﻣﻮﺍﺻﻔﺎﺕ
2ﻣﻢ+2ﺟﺰءﻟﻜﻞﻣﻠﻴﻮﻥ
)0.1ﺑﻮﺻﺔ+2ﺟﺰءﻟﻜﻞﻣﻠﻴﻮﻥ(
ﺗﻌﺎﻗﺐﺍﻟﻤﻨﺸﻮﺭ
3ﻣﻢ
)0.1ﺑﻮﺻﺔ(
ﻋﺪﻳﻢﺍﻟﻌﻮﺍﻛﺲ
2ﻣﻢ+2ﺟﺰءﻟﻜﻞﻣﻠﻴﻮﻥ
)0.1ﺑﻮﺻﺔ+2ﺟﺰءﻟﻜﻞﻣﻠﻴﻮﻥ(
4.5ﺗﺘﺒﻊﺍﻟﻬﺪﻑ)ﻣﺘﻌﻘﺐLED(
ﻃﻮﻝﺫﺭﻭﺓﺍﻟﻤﻮﺟﺔ
≥810ﻧﺎﻧﻮﻣﺘﺮ
ﺷﺪﺓﺍﻹﺷﻌﺎﻉﺍﻟﻨﻤﻮﺫﺟﻴﺔﻋﻠﻰﻣﺴﺎﻓﺔ20ﺳﻢ)108ﻣﻴﻜﺮﻭ
ﺛﺎﻧﻴﺔ/109ﻫﺮﺗﺰ(
3ﻣﻠﻠﻲﻭﺍﻁ/ﺳﻢ²
ﺃﻗﺼﻰﺷﺪﺓﻟﻺﺷﻌﺎﻉﻋﻠﻰﻣﺴﺎﻓﺔ20ﺳﻢ
0.24ﻣﻠﻠﻲﻭﺍﻁ/ﺳﻢ²
ﻣﺪﺓﺍﻟﻨﺒﺾﺍﻟﻘﺼﻮﻯ
108ﻣﻴﻜﺮﻭﺛﺎﻧﻴﺔ
ﺗﺮﺩﺩﺍﻟﻨﺒﺾﺍﻷﻗﺼﻰ
330ﻫﺮﺗﺰ
ﺗﺒﺎﻋﺪﺍﻟﺤﺰﻣﺔ)2θ
1/2
(
20ﺩﺭﺟﺔ
ﻧﻄﺎﻕﺍﻟﺘﺘﺒﻊPOA 25
1.5ﻡ…100ﻡ
)4ﻗﺪﻡ—11ﺑﻮﺻﺔ…
328ﻗﺪﻡ(
ﻧﻄﺎﻕﺍﻟﺘﺘﺒﻊPOA 20
1.5ﻡ…400ﻡ
)4ﻗﺪﻡ—11ﺑﻮﺻﺔ…
1,312ﻗﺪﻡ(

Hilti PLT 400 Specifications

General

Power Supply	Li-ion Battery
Laser Class	Class 2
IP Protection Class	IP54
Rotation Speed	600 rpm
Self-Leveling Range at Room Temperature	±5°
Operating Temperature	-20 - 50 °C
Laser Type	635 nm
Battery Type	Li-ion
