Electrical schematic
Main technical spec
Dimension(L*W*H)
1470
×
610
×
1095MM
Front and rear wheel center distance 960MM
Max weight 21.6KG
Speed 25KM/H
Assisting distance range ≈ 80KM
Electricity consumption(100KM) 0.72KWH
Loading weight ≤100KG
This assisting distance range is tested in the condition of full power, loading capacity 75kg,
temperature about 25°C, flat road, no wind environment. It is measured in the energy-
saving mode of 15km/h. The performance will be varied due to load, temperature, wind
speed, road surface, operation habits and other factors.
Battery spec
Battery type lithium-ion battery
Capacity 10AH
Voltage 36V
Motor spec
Type brushless DC motor
Rated power 250W
Rated speed 380R/MIN
Voltage 36V
Controller spec
Undervoltage protection 31V
Overcurrent protection 15A
