Steps to Use the Tire Pump in the Seat Tube
1.Open the clamp on the
quick-release seat tube to
remove the seat tube;
2. Remove the nut on the
seat tube to pull out the pump
unit;
3.Plug tightly the pump
mouth into the cycle valve;
4.Turn the buckle by 90
degrees and hold the seat
cushion to start pumping.
Taillight opening and maintenance Replacement of batteries
Rear reflector
Tail lamp
Switch
Press to open the quick-release battery compartment
as shown in the figure.
Replace the spent batteries with new ones.
Close the battery compartment.
The tail light is designed with an indepen-
dent switch; to use it, just press the switch.
(This is just a schematic diagram. Please
subject to the available product.)
No.7 batteries
2 pcs
