Part # Qty.
A Left End Frame 4031 1
B Right End Frame 4030 1
C Front left roller support guide 4025 1
D Front right roller support guide 4026 1
E Right template support 4028 1
F Left template support 4029 1
G Angle brace 1 4056 2
H Angle brace 2 4057 2
I Middle roller support guide 4027 2
J Ratchet Wheels 4017 3
K Left rear roller support 4006 1
L Left middle roller support 4032 1
M Left spacer 4012 1
N Left front roller support 4016 1
O Right middle roller support 4033 1
P Right rear roller support 4005 1
Q Right spacer 4011 1
R Right front roller support 4015 1
S Pawl 4013 2
T Pawl 4014 1
U Upper Carriage MQF UC 1
V Lower Carriage MQF LC 1
W Top support w/ square hole 4077 1
X Top support w/ round hole 4078 1
Y Center Support Roller Bracket 4076 2
Z Center Support Upright 4083 1
MACHINE FRAME WOOD PARTS LIST
