Installation EAGLE20/30
Release
06
04/2014
21
1.4.2 Rear view
1.5 Power supply
1.5.1 Working voltage with the characteristic value K
A 3-pin terminal block is available to supply the device.
For further information see: “Working voltage with the characteristic value K”
on page 31.
1.5.2 Working voltage with the characteristic value C
For the redundant supply of the device, two 2-pin terminal blocks are
available.
For further information see: “Working voltage with the characteristic value C”
on page 32.
1 Slot for the SD card
2 Knurled screw
1
2
