Hirschmann MACH 1020 User Manual

60
Installation MACH 1000
Release 04 12/2015
IEEE C37.90.1 Fast transients (burst)
DC Power Line ± 4 kV
AC Power Line ± 4 kV
Data line ± 4 kV
IEEE C37.90.1 Damped oscillation
DC Power Line ± 2,5 kV line/earth; ± 1 kV
line/line
AC Power Line ± 2,5 kV line/earth; ± 1 kV
line/line
Data line ± 2,5 kV line/earth; ± 1 kV
line/line
IEEE C37.90 H.V. Impulse
DC Power Line ± 5 kV line/earth
AC Power Line ± 5 kV line/earth
IEEE C37.90 dielectric strength
DC Power Line, power unit type „C“,
„L“
500 V AC
AC Power Line, power unit type „G“,
„M“
2000 V AC
DC Power Line, power unit type „G“,
„M“
2000 V AC
signal contact type „C“, „L“ and „G“,
„M“
2000 V AC
EMC interference emission
EN 55022 Class A
FCC 47 CFR Part 15 Class A
German Lloyd Classification + Construction Guidelines VI-7-3 Part 1 Ed.2001
Environment type
tests, test in comp.
with
Description Test level
IEC 60068-2-1 Cold −40 °F (−40 °C), 16 hours
IEC 60068-2-2 Dry heat +185 °F (+85 °C), 16 hours
IEC 60068-2-30 Relative humidity 95 % (non condensing)
131 °F (55 °C), 4 cycles
IEC 60068-2-6 Vibration, test Fc 2 - 9 Hz with 3 mm amplitude
1 g at 9 - 150 Hz
1.5 g at 200 - 500 Hz
IEC 60068-2-27 Shock, test Ea 15 g at 11 ms
EMC interference
immunity
IEEE 1613:2009 EMI
TYPE tests, test in
comp. with
Description Test level
