Hisense 32E5606EX - Page 11

- 11 -
Board PB732 terminals layout:
Position Description Market
1 AV3 Digital Audio out
2 CN4 SERVICE
3 RFT1 RF Input
Tuner part on board
4 CNA2 Earphone
5 AVH2 HDMI1(ARC)
6 AVH1 HDMI2
7 CN12 USB *2
8 CN5 LAN
9 CN2 WIFI
10 CN6 IR&KEY
11 AV2 AV
12 CNA3 SPEAKER
13 CNB801 LED DRIVER
14 CNB1 Power input
