POWER_DETECT_IC
AUVAG
AUVRM
XTALI
PCM_OE_N
PCM_IORD_N
PCM_CD_N
PCM_CE_N
PCM_IOWR_N
PCM_IRQA_N
PCM_WE_N
PCM_WAIT_N
PCM_REG_N
PCM_RESET
BT_WAKE_IC
DISEQC_IC
DVDD_NODIE2_IC
DVDD_NODIE1_IC
DVDD_NODIE3_IC
System-RST
XTALO
Close to MST IC
with width trace
POWER_DETECT
Close to MST IC
with wide trace
如下需要在top层
CHIP_CONFIG[3:0]
{GPIO_PM[2]，GPIO_PM[9], GPIO_PM[10], PWM_PM}
Value Mode Description
3'b1010 HEMCU_ROM_EMMC EMMC
3'b1011 HEMCU_ROM_NAND Nand
一定要注意外围电路不要影响到config
EMMC_D1_IC
EMMC_D2_IC
EMMC_D3_IC
EMMC_D4_IC
EMMC_D5_IC
EMMC_D6_IC
EMMC_D7_IC
EMMC_D0_IC
EMMC_CMD_IC
EMMC_CLK_IC
EMMC_RST_IC
C100
NC/10uF-0603-X5R-¡À20%-6.3V
C107
1uF-0402-X5R-¡À20%-6.3V
C106
1uF-0402-X5R-¡À20%-6.3V
C105
1uF-0402-X5R-¡À20%-6.3V
R47
厚膜电阻,RES,1/16W,68ohm,¡À5%,0402,SMD
C116
0.047uF-0402-X7R-¡À10%-16V
R63
厚膜电阻,RES,1/16W,4.7Kohm,¡À5%,0402,SMD
R64
厚膜电阻,RES,1/16W,1Kohm,¡À1%,0402,SMD
R65
厚膜电阻,RES,1/16W,1Kohm,¡À1%,0402,SMD
R68
NC/厚膜电阻,RES,1/16W,4.7Kohm,¡À5%,0402,SMD
R71
厚膜电阻,RES,1/16W,4.7Kohm,¡À5%,0402,SMD
R72
厚膜电阻,RES,1/16W,1Kohm,¡À1%,0402,SMD
12V
R38
4K7ohm-0402-¡À5%-1/16W
R32
厚膜电阻,RES,1/16W,4.7Kohm,¡À5%,0402,SMD
R33
厚膜电阻,RES,1/16W,4.7Kohm,¡À5%,0402,SMD
R55
厚膜电阻,RES,1/16W,4.7Kohm,¡À5%,0402,SMD
R56
厚膜电阻,RES,1/16W,4.7Kohm,¡À5%,0402,SMD
3V3_M
PHY_TX_P_IC
PHY_TX_N_IC
PHY_RX_P_IC
PHY_RX_N_IC
CVBS_IN_IC
TSI_D1
TSI_D0
TSI_D3
TSI_D2
TSI_D6
TSI_D5
TSI_D4
TSI_D7
TSO_D5
TSO_D4
TSO_D3
TSO_D7
TSO_D6
TSO_D1
TSO_D0
TSO_D2
TSO_SYNC
TSO_VLD
TSO_CLK
TSI_SYNC
TSI_CLK
TSI_VLD
HDMI1_RX2P_IC
HDMI1_RX2N_IC
HDMI1_RX1P_IC
HDMI1_RX1N_IC
HDMI1_RX0P_IC
HDMI1_RX0N_IC
HDMI1_CLKP_IC
HDMI1_CLKN_IC
HDMI1_SCL_IC
HDMI1_SDA_IC
HDMI1_HPD_IC
HDMI_CEC_IC
HDMI2_RX2P_IC
HDMI2_RX2N_IC
HDMI2_RX1P_IC
HDMI2_RX1N_IC
HDMI2_RX0P_IC
HDMI2_RX0N_IC
HDMI2_CLKP_IC
HDMI2_CLKN_IC
HDMI2_SCL_IC
HDMI2_SDA_IC
HDMI2_HPD_IC
HDMI3_RX2P_IC
HDMI3_RX2N_IC
HDMI3_RX1P_IC
HDMI3_RX1N_IC
HDMI3_RX0P_IC
HDMI3_RX0N_IC
HDMI3_CLKP_IC
HDMI3_CLKN_IC
HDMI3_SCL_IC
HDMI3_SDA_IC
HDMI3_HPD_IC
HDMI_ARC_IC
I2S_BCK_IC
I2S_MCK_IC
I2S_SD_IC
I2S_WS_IC
AMP_MUTE_IC
IP_S_IC
QP_S_IC
IM_S_IC
QM_S_IC
LNB_PWEN_IC
LNB_13V/18V_SEL_IC
VIFP_IC
VIFM_IC
PCM_D7
PCM_D3
PCM_D6
PCM_D5
PCM_D4
PCM_D2
PCM_D1
PCM_D0
PCM_A7
PCM_A12
PCM_A2
PCM_A3
PCM_A4
PCM_A5
PCM_A6
PCM_A0
PCM_A1
PCM_A9
PCM_A10
PCM_A14
PCM_A13
PCM_A8
PCM_A11
USB0_D-
USB0_D+
USB1_D+
USB1_D-
EARPHONE_OUTL_IC
EARPHONE_OUTR_IC
S_IF_AGC_IC
PANEL_ON/OFF_IC
EMMC_DS_IC
USB2_D+
USB2_D-
WIFI
BRI_ADJ_IC
PWR_OFF_CTR_IC
VID_0_IC
DDC_SDA_IC
DDC_SCL_IC
T_IF_AGC_IC
IR_DATA_IC
KEY0_IN_IC
DDC_SDA_IC
DDC_SCL_IC
PWR_ON/OFF_IC
I2C-SCL_IC
I2C-SDA_IC
I2C-SCL_IC
I2C-SDA_IC
PANEL_IIC_SDA
PANEL_IIC_SCL
PCB短路
R1
NC/0ohm-0402-PCB
HDMI/Audio Block
HDMI1_DETECT_IC
PCMCIATS/EMMC/FE
SD_CLK_IC
SD_D2_IC
SD_CMD_IC
SD_D0_IC
SD_D3_IC
SD_D1_IC
R70
0ohm-0402-¡À5%-1/16W
RGB/CVBS/PHY/USB Block
LED_R_IC
R29
100ohm-0402-¡À5%-1/16W
R30
100ohm-0402-¡À5%-1/16W
UART-RX_IC
UART-TX_IC
R28
4K7ohm-0402-¡À5%-1/16W
R27
4K7ohm-0402-¡À5%-1/16W
UART-RX
UART-TX
D3
NC/AVLC18S02003
D2
NC/AVLC18S02003
走线太长，靠主IC放
3V3_STB
UART-RX_IC
UART-TX_IC
GND
UART(Service Port)
Boot Config
3V3_STB
LNB_PWEN_IC
LNB_13V/18V_SEL_IC
LED_R_IC
POWER_DETECT_IC
WIFI_RESET_IC
LVDS/GPIOIIC
系统主I2C，挂TUNER、AMP
R36
100ohm-0402-¡À5%-1/16W
R37
100ohm-0402-¡À5%-1/16W
3V3_M
DDC_SDA
DDC_SCL
NOTE:晶体频偏需要小于30PPM
XTAL
XTALI
XTALO
C1=C2=2*CL-5
1 3
2 4
Y1
无源标准封装晶体振荡器,SPXO,24MHz,¡À20ppm,16pF,3.2¡Á2.5,SMD,SMD3225 24.000MHZ ,JWT
GND
GND
3V3_STB
R50
厚膜电阻,RES,1/16W,11Kohm,¡À1%,0402,SMD
C99
2.2uF-0402-X5R-¡À20%-6.3V
C63
陶瓷电容,CAP MC,50V,22pF,¡À5%,NPO,0402,SMD,T P
C64
陶瓷电容,CAP MC,50V,22pF,¡À5%,NPO,0402,SMD,T P
RESET
Q1
NC/LMBT3904LT1G
R61
NC/33Kohm-0402-¡À5%-1/16W
R57
NC/2K2ohm-0402-¡À5%-1/16W
Q2
NC/LMBT3906LT1G
GND GND
R59
NC/33Kohm-0402-¡À5%-1/16W
12V
R54
NC/2Kohm-0402-¡À1%-1/16W
R60
NC/NC/470Kohm-0402-¡À5%-1/16W
R58
NC/100Kohm-0402-¡À5%-1/16W
GND
C93
NC/10uF-0805-X5R-¡À20%-16V
D4
NC/1N4148WS
AC_OFF_DET
When 12V drops to 9.6V, AC_DET_DROP outputs 80mS low voltage.
R53
NC/0ohm-0402-¡À5%-1/16W
RR3
NC/100Kohm-0402-¡À5%-1/16W
GND
RR2
NC/1Kohm-0402-¡À5%-1/16W
3V3_STB
DR1
NC/AVLC18S02003
CR1
NC/0.1uF-0402-X5R-¡À20%-16V
RR1
NC/1Kohm-0402-¡À5%-1/16W
copy自950
System-RST
DC DROP DETECT circuit
D5
NC/AVLC18S02003
D6
NC/AVLC18S02003
GND GND
LNB+1V_IC
WIFI_WAKE_IC
TS
Front End
EMMC
SD
EMMC_IO0/NAND_D4
AE7
EMMC_IO1/NAND_D3
AE8
EMMC_IO2/NAND_D2
AD8
EMMC_IO3/NAND_D5
AD7
EMMC_IO4/NAND_D6
AC6
EMMC_IO5/NAND_D7
AD6
EMMC_IO6/NAND_D0
AD9
EMMC_IO7/NAND_D1
AC8
EMMC_DS
AD10
EMMC_IO9/EMMC_CMD/NAND_CEZ
AD11
EMMC_IO10/EMMC_CLK/NAND_REZ
AE11
EMMC_IO11/EMMC_RSTn/NAND_WEZ
AE10
SD_D0
AB9
SD_D1
AA9
SD_D2
Y10
SD_D3
Y9
SD_CLK
AA10
SD_CMD
AB10
TS2_D0
Y11
TS2_SYNC
AA11
TS2_VLD
AB11
TS2_CLK
AA12
TS0_D0
AC20
TS0_D1
AD21
TS0_D2
AC21
TS0_D3
AD22
TS0_D4
AE22
TS0_D5
AC22
TS0_D6
AE23
TS0_D7
AD23
TS0_SYNC
AD20
TS0_VLD
AC19
TS0_CLK
AE20
TS1_D0
AC16
TS1_D1
AE17
TS1_D2
AD17
TS1_D3
AC17
TS1_D4
AD18
TS1_D5
AC18
TS1_D6
AD19
TS1_D7
AE19
TS1_SYNC
AE16
TS1_VLD
AC15
TS1_CLK
AD16
VIFP
AD3
VIFM
AC3
IF_AGC
AE4
TGPIO0_PM
AD4
TGPIO1_PM
AC4
U1B
客供TV主芯片,IC Main Chip,SMD,MSD6683BQHT-8-00GE,Hisense,Mstar
HDMI
Analog
Audio
SPDIF
I2S
EARPHONE_OUTL
AB5
EARPHONE_OUTR
AB6
LINEIN_L0
V2
LINEIN_L4
W2
LINEIN_R0
V3
LINEIN_R4
W3
AUVAG
V1
AUVRM
U3
SPDIF_IN
E10
SPDIF_OUT
D10
I2S_OUT_BCK
D9
I2S_OUT_MCK
F8
I2S_OUT_SD
E8
I2S_OUT_WS
D8
PAD_RX0N
J1
PAD_RX0P
J2
PAD_RX1N
K3
PAD_RX1P
K2
PAD_RX2N
L3
PAD_RX2P
L2
PAD_RXCN
H1
PAD_RXCP
J3
ARC0
J4
PAD_B_RX0N
E2
PAD_B_RX0P
F1
PAD_DDCDA_CK
L5
PAD_DDCDA_DA
M5
PAD_DDCDB_CK
K4
PAD_DDCDB_DA
K5
PAD_DDCDC_CK
J5
PAD_DDCDC_DA
H5
PAD_HOTPLUGA
M6
PAD_HOTPLUGB
L6
PAD_HOTPLUGC
J6
PAD_B_RX2P
H3
PAD_B_RXCN
D3
PAD_B_RXCP
E1
PAD_B_RX2N
G2
PAD_B_RX1N
F2
LINEOUT_L0
AA5
LINEOUT_R0
AA6
PAD_B_RX1P
G3
PAD_CEC0
P6
PAD_C_RX0N
B3
PAD_C_RX0P
B2
PAD_C_RX1N
B1
PAD_C_RX1P
C2
PAD_C_RX2N
C1
PAD_C_RX2P
D2
PAD_C_RXCN
A3
PAD_C_RXCP
A2
LINEOUT_L2
Y6
LINEOUT_R2
Y5
DVDD_NODIE/PAD_HOTPLUGA_HDMI20_5V
N6
DVDD_NODIE/PAD_HOTPLUGB_HDMI20_5V
M4
DVDD_NODIE/PAD_HOTPLUGC_HDMI20_5V
K6
U1C
客供TV主芯片,IC Main Chip,SMD,MSD6683BQHT-8-00GE,Hisense,Mstar
PWM
SAR
GPIO
Vx1/LVDS
PM_GPIO
SAR0
E4
SAR1
B7
PANEL_ON/OFF
E5
SAR3
D4
PWM_PM
G5
BRI_ADJ
N22
PWM1
N21
DDCA_CK/UART0_RX
AB4
DDCA_DA/UART0_TX
AA4
DDCR_DA
F9
TESTPIN
D5
POWER_DET
F6
MOD_TX_P02/R_ODD[7]
L23
MOD_TX_P03/R_ODD[5]
M25
MOD_TX_P04/R_ODD[3]
N24
MOD_TX_P05/R_ODD[1]
P23
MOD_TX_P06/G_ODD[7]
R23
MOD_TX_P07/G_ODD[5]
T23
MOD_TX_P08/G_ODD[3]
V24
MOD_TX_P09/G_ODD[1]
W25
MOD_TX_N04/R_ODD[2]
N23
MOD_TX_N05/R_ODD[0]
R24
MOD_TX_N07/G_ODD[4]
U24
MOD_TX_N08/G_ODD[2]
V25
MOD_TX_N09/G_ODD[0]
W24
MOD_TX_P00/VSYNC
K25
MOD_TX_P01/DE
K24
GPIO_PM[5]/PM_UART_RX
G6
VBL_CTRL
F3
GPIO_PM[10]
AC1
PWR-ON/OFF
G4
GPIO_PM[9]
AC2
VID0
F4
VID1/PWR_OFF_CTR
F7
LD_SPI_CK/TS2_D[7]
P21
MOD_TX_N06/G_ODD[6]
T25
MOD_TX_N01/LCK
K23
MOD_TX_N02/R_ODD[6]
M24
MOD_TX_N03/R_ODD[4]
M23
MOD_TX_N00/HSYNC
J23
DDCR_CK
E9
LD_SPI_MISO/TS2_D[4]
N20
LD_SPI_CS/TS2_D[5]
R21
LD_SPI_MOSI/TS2_D[6]
P20
MOD_TX_P10/B_ODD[7]
Y24
MOD_TX_N10/B_ODD[6]
Y23
MOD_TX_P11/B_ODD[5]
AA25
MOD_TX_N11/B_ODD[4]
AA23
MOD_TX_P12/B_ODD[3]
AB24
MOD_TX_N12/B_ODD[2]
AC25
MOD_TX_P13/B_ODD[1]
AD25
MOD_TX_N13/B_ODD[0]
AD24
GPIO_PM[1]/PM_UART_TX
H6
GPIO_PM[2]
E6
GPIO_PM[3]
T2
GPIO_PM[6]
Y2
GPIO_PM[8]
T3
GPIO_PM[7]
AA8
U1D
客供TV主芯片,IC Main Chip,SMD,MSD6683BQHT-8-00GE,Hisense,Mstar
RGB
CVBS
USB
PHY
CVBS_OUT1
N4
BIN1P
P1
GIN0M
P3
GIN0P
N2
HSYNC0
M1
RIN1P
R2
VSYNC0
M2
HWRESET
P5
XIN
AD1
XOUT
AE2
IRIN
F5
DM_P0
A9
DM_P1
C9
DM_P2
C8
DP_P0
B9
BIN0P
N3
CVBS0
R4
GIN1M
R1
GIN1P
R3
RIN0P
P2
VCOM
N5
DP_P1
B8
DP_P2
A7
TN
B5
TP
C5
RN
B6
RP
C6
DP_P3(NC)
AD5
DM_P3(NC)
AE5
HSYNC1
R5
VSYNC1
R6
SPI2_DI/VBUS
H22
SPI2_CK/CID
J22
U1E
客供TV主芯片,IC Main Chip,SMD,MSD6683BQHT-8-00GE,Hisense,Mstar
PCM_D0
R20
PCM_D1
R22
PCM_D2
T21
PCM_D3
Y17
PCM_D4
AB17
PCM_D5
AA16
PCM_D6
AB18
PCM_D7
AA17
PCM_A0
T20
PCM_A1
U20
PCM_A2
U21
PCM_A3
U22
PCM_A4
W21
PCM_A5
Y21
PCM_A6
Y22
PCM_A8
AA20
PCM_A9
AB20
PCM_IOWR_N
AA19
PCM_A11
AB19
PCM_A7
Y20
PCM_A12
AB23
PCM_RESET
W22
PCM_IRQA_N
AA22
PCM_OE_N
Y19
PCM_A10
Y18
PCM_A14
AA21
PCM_A13
AB21
PCM_WAIT_N
W20
PCM_IORD_N
W19
PCM_CD_N
P22
PCM_REG_N
V21
PCM_WE_N
AB22
PCM_CE_N
AA18
IP_S
AA3
IM_S
AA2
QP_S
AB3
QM_S
AB2
IFAGC_S
Y1
GPIO13/DISEQC_OUT
AA1
U1H
客供TV主芯片,IC Main Chip,SMD,MSD6683BQHT-8-00GE,Hisense,Mstar
DVDD_NODIE2_IC
DVDD_NODIE1_IC
DVDD_NODIE3_IC
UART-RX
UART-TX
UART_GND
UART-TX
UART-RX
GND
2
1
3
GND
RESET V cc
UR1
NC/复位IC,IC Reset,HIGH,2.93V,SOT23-3,SMD,SGM810-SXN3L,SGMICRO
GND
GND
AMP LIN_ IC
AMP RIN_ IC
单层USB
双层USB第二组
SPDIF_OUT_IC
AV_LIN_IC
AV_RIN_IC
GPIO_PM2_IC
CVBS_OUT_IC
R6
厚膜电阻,RES,1/16W,4.7Kohm,¡À5%,0402,SMD
R31
厚膜电阻,RES,1/16W,4.7Kohm,¡À5%,0402,SMD
3V3_M
PANEL_IIC_SDA
PANEL_IIC_SCL
1
4
2
3
5
6
GND
EP_R
EP_L
DET
GND
CN4
耳机端子,Earphone Jack,H,Φ3.5,CH7.0,Black,switch,Seal,SMD,PJ7724H-F05L3BE-F,YUQIU
GPIO_PM2_IC
配Nand Flash还要更改供电
CVBS_OUT
C29
NC/0.1uF-0402-X5R-¡À20%-16V
DV1
NC/AVLC18S02003
DV2
NC/AVLC18S02003
GND
LV_RXO0N_IC
LV_RXO1N_IC
LV_RXO2N_IC
LV_RXOCKN_IC
LV_RXO0P_IC
LV_RXO1P_IC
LV_RXO2P_IC
LV_RXOCKP_IC
LV_RXE0N_IC
LV_RXE1N_IC
LV_RXE2N_IC
LV_RXE3N_IC
LV_RXE0P_IC
LV_RXE1P_IC
LV_RXE2P_IC
LV_RXE3P_IC
LV_RXECKN_IC
LV_RXECKP_IC
LV_RXE4N_IC
LV_RXE4P_IC
LV_RXO3N_IC
LV_RXO3P_IC
LV_RXO4N_IC
LV_RXO4P_IC
PANEL_GMA_WP
3V3_M
RG80
厚膜电阻,RES,1/16W,47Kohm,¡À5%,0402,SMD
HP_DET_IC
IIC_WP_IC
HP_MUTE_IC
HDMI2_DETECT_IC
M_USBEN_IC
VBL_CTRL_IC
R41
NC/4K7ohm-0402-¡À5%-1/16W
3V3_STBC117
NC/0.047uF-0402-X7R-¡À10%-16V
To Next Page
Loading...
