D D
C C
B B
A A
RG8
0ohm-0402-¡À5%-1/16W
CG8
2200pF-0402-X7R-¡À10%-50V
CG12
陶瓷电容,CAP MC,25V,10uF,¡À10%,X5R,0805,SMD,T P
CG11
陶瓷电容,CAP MC,25V,10uF,¡À10%,X5R,0805,SMD,T P
GND
VGL_CS
LX/AVDD
NWR-302
COMPA
VGL:-10.6
VGH:30
AVDD:15.1
VSSG:-8
VSSQ:-9.4
CG23
NC/1000pF-0402-X7R-¡À10%-50V
RG18
33Kohm-0402-¡À5%-1/16W
CG25
陶瓷电容,CAP MC,50V,1000pF,¡À20%,X7R,0402,SMD,T P
GND
GND
VCC_PANEL
GND
RG30
0ohm-0402-¡À5%-1/16W
A0
RG29
NC/0ohm-0402-¡À5%-1/16W
VDC
GATEN
VGL
GND
DVDD33
GND
DVDD33
GND
VCC_PANEL
GND
VDC
VT
GND
COMPGH
VGH_CS
GND
CG22 1uF-0603-X5R-¡À10%-50V
VGH1
GATEP
SCL-302-T
SDA-302-T
RG223
NC/22Kohm-0402-¡À5%-1/16W
GND
DRVSS
GD
OSI
AVDD
CG7
陶瓷电容,CAP MC,25V,0.1uF,¡À20%,X5R,0402,SMD,T P
CG6
陶瓷电容,CAP MC,25V,10uF,¡À10%,X5R,0805,SMD,T P
CG3
NC/陶瓷电容,CAP MC,25V,10uF,¡À10%,X5R,0805,SMD,T P
CG117
NC/陶瓷电容,CAP MC,25V,0.1uF,¡À20%,X5R,0402,SMD,T P
AVDD
GND
RG224
5K6ohm-0402-¡À1%-1/16W
RG225
150Kohm-0402-¡À1%-1/16W
GND
TH1
热敏电阻,RES NTC,100mW,0.11mA,68Kohm,¡À1%,0402,SMD,T P,Sunlord
VT
RG27
120Kohm-0402-¡À1%-1/16W
CG37
120pF-0402-NPO-¡À5%-50V
CG35
NC/陶瓷电容,CAP MC,25V,10uF,¡À10%,X5R,0805,SMD,T P
GND
COMPGH
GATEN
VGL_CS
VCC_PANEL
RG33
20Kohm-0402-¡À1%-1/16W
RG43
0ohm-0402-¡À5%-1/16W
GND
GND
RG56
NC/?
VGL
AVDD
CG45
陶瓷电容,CAP MC,25V,10uF,¡À10%,X5R,0805,SMD,T P
GND
LG4
NC/功率电感,Power Inductor,10uH,¡À20%,2.45A,DR6.0*4.5,SMD,SWPA6045S100MT ,Sunlord
GATEP
RG54
20Kohm-0402-¡À1%-1/16W
GND
VGH_CS
VGH1
CG48
0.1uF-0603-X7R-¡À10%-50V
VGH
SDA-302-T
SCL-302-T
RG58
100ohm-0402-¡À5%-1/16W
NWR-302
SDA-1
SCL-1
NWR-1
VGH VGL
此NMOS需换为大电流物料
GND
DG1
肖特基二极管,DIO SBD S,3A,40V,SMA,SMD,SS34A,YJ
VCC_PANEL
LG1
功率电感,Power Inductor,10uH,¡À20%,2.45A,DR6.0¡Á4.5,SMD,PRS6045-100MT P02,FH
LX/AVDD
GND
GND
CG15
10uF-0805-X5R-¡À20%-16V
CG14
10uF-0805-X5R-¡À20%-16V
CG13 NC/0.1uF-0402-X5R-¡À20%-16VCG10
NC/1uF-0603-X5R-¡À10%-25V
RG34
0R1ohm-1206-¡À1%-1/4W
RG35
0R1ohm-1206-¡À1%-1/4W
此电容＜10uF
LX/AVDD_CS
2
AVDD_GATE
4
PGND
3
LX/AVDD_CS
1
NWR
5
COMPA
6
VC
7
DRVN
16
A0
15
GATEN
14
VGL_CS
13
VIN_VC
12
VIN_VC
11
LX_VC
10
PGND
8
LX_VC
9
VGL
17
OUTB
18
LXB
19
LXB
20
VIN
21
VIN
22
AGND
23
VDC
24
VT
26
EN
25
COMPGH
27
PGND
28
VGH
29
DRVP/VGH_CS
30
GATEP
31
SCL
32
SDA
33
SET
34
VCOMADJ
35
VCOMNEG
36
VCOM
37
OSO
38
OSI
39
EPAD
41
AVDD_EGD
40
UG1
DC-DC芯片,IC DCDC,Syn,4.3A,14V,500KHz,VQFN-40L,SMD,AUO-P303.11,Richtek
D
G
S
QG1
场效应管,PMOS,-4.3A,-30V,0.048ohm@ID=-3A@VGS=-4.5V,SOT-23-3L,NCE3407AY,NCEPOWER
RG55
0R2ohm-1206-¡À1%-1/4W
RG45
33ohm-0402-¡À5%-1/16W
RG48
33ohm-0402-¡À5%-1/16W
D
G
S
QG5
场效应管,PMOS,-4.3A,-30V,0.048ohm@ID=-3A@VGS=-4.5V,SOT-23-3L,NCE3407AY,NCEPOWER
QG6
场效应管,NMOS,2.6A,60V,82mohm@ID=2.6A@VGS=10V,SOT-23,ME2308S-G,MATSUKI
CG46
陶瓷电容,CAP MC,50V,10uF,¡À10%,X5R,1206,SMD,T P
CG47
NC/陶瓷电容,CAP MC,50V,10uF,¡À10%,X5R,1206,SMD,T P
RG3
22ohm-0603-¡À5%-1/10W
RG20
NC/?
CG9
0.047uF-0603-X7R-¡À10%-25V
RG46
0ohm-0402-¡À5%-1/16W
CG16
180pF-0402-NPO-¡À5%-50V
RG47
NC/22ohm-0603-¡À5%-1/10W
CG49
NC/180pF-0402-NPO-¡À5%-50V
PMIC
CG26
陶瓷电容,CAP MC,16V,1uF,¡À20%,X5R,0402,SMD,T P
CG38
陶瓷电容,CAP MC,16V,0.1uF,¡À20%,X5R,0402,SMD,T P
CG36
10uF-0805-X5R-¡À20%-16V
CG41
陶瓷电容,CAP MC,16V,1uF,¡À20%,X5R,0402,SMD,T P
CG27
10uF-0805-X5R-¡À20%-16V
CG40
陶瓷电容,CAP MC,6.3V,22uF,¡À20%,X5R,0603,SMD,T P
CG54
NC/陶瓷电容,CAP MC,6.3V,22uF,¡À20%,X5R,0603,SMD,T P
CG39
陶瓷电容,CAP MC,6.3V,22uF,¡À20%,X5R,0603,SMD,T P
CG42
10uF-0805-X5R-¡À20%-16V
CG50
10uF-0805-X5R-¡À20%-16V
CG51
NC/10uF-0805-X5R-¡À20%-16V
CG24
陶瓷电容,CAP MC,16V,0.1uF,¡À20%,X5R,0402,SMD,T P
0x70
I2C ADDRESS
Write
Read
0x71
PANEL_IIC_SDA
PANEL_IIC_SCL
DG9
肖特基二极管,DIO SBD S,1A,40V,DO-214AC,SMD,SS14A,YJ
DG10
肖特基二极管,DIO SBD S,1A,40V,DO-214AC,SMD,SS14A,YJ
VSSG
IIC
+
EG1
铝电解电容,CAP AL,25V,100uF,¡À20%,L D,VB,6.3¡Á7.7,SMD,T P,Chang
PCB短路
RG40
NC/0ohm-0603-PCB
DG8
肖特基二极管,DIO SBD S,1A,40V,DO-214AC,SMD,SS14A,YJ
-9.5V 0.15A
30.3V 0.2A
3.3V, 1A
16.3V 1.5A
LG5
功率电感,Power I nductor,10uH,¡À20%,1.5A,DR4.0¡Á3.0,SMD,NRH4030-10uH,wenshan
LG2
功率电感,Power I nductor,10uH,¡À20%,1.5A,DR4.0¡Á3.0,SMD,NRH4030-10uH,wenshan
DG6
开关二极管,DIO SW S,150mA,75V,SOD-323,SMD,1N4148WS,BLUE ROCKET
RG79
NC/4K7ohm-0402-¡À5%-1/16W
3V3_M
LG3
功率电感,Power Inductor,6.8uH,¡À20%,1.3A,0.23¡Á1P,DR4.5¡Á3.2,SMD,PI O43-6R8MTP02,FH
CG1
NC/10uF-0805-X5R-¡À20%-16V
CG2
NC/10uF-0805-X5R-¡À20%-16V
VSSG
IIC_WP_IC
