6
Attach the Wall Mount Bracket (not included)
Before you begin the third-party manufacturer instructions, be
sure to do the following things:
1.Place the TV f ace down on a clean, safe and cushioned surface.
2.Remove the TV stand if you already attached it.
3.Place the spacers (not included) in the corresponding bracket
holes.
CAUTION:
• When you attach the mount, be sure to use the spacers
(provided by the third-party manufacturer) between the TV
and the bracket.
•
To prevent internal damage to the TV and ensure it is
mounted securely, be sure to use screws (not
provided) that are 8 - 10 mm(
32") in length when
Follow instructions provided with the Wall mount bracket.
● To complete the installation, please contact the wall-mount
manufacturer or the retailer from which you purchased the TV.
●
The selected screws are 8-10 mm(32") in length when
measured from the attaching surface of the rear cover.
NOTE: The diameter and length of the screws differ
depending on the wall mount bracket model.
Rear cover of the TV Spacer
Screw
Wall mount bracket
W
all mount hole pattern
VESA (mm)
100 × 100
Wall mount screw size M4
8.0~10.0mm(32")
Screw
(not provided)
Bracket
(not provided)
Spacer
(not provided)
measured from the attaching surface of the mounting
hook.
