3
Connection
Terminals
or
ANT OUT
ANT
DVB-T/T2/C
ANT
DVB-S/S2
HDMI
DVD/Blu-Ray/AV receiver/
Set-top Box
HDMI
Audio Amplier/Speaker
HDMI (eARC)
HDMI
Audio Amplier/Speaker
HEADPHONE
DC 5V 0.5A(MAX)
USB
CAM CARD
NOTE
Excessive sound pressure from
earphones and headphones can cause
hearing loss.
NOTE
Do not repeatedly insert or remove the Common
Access Module as this may damage the interface and
cause a malfunction.
You must obtain a CI+ module and card from the
service provider of the channels you want to watch.
CI+ is not supported in some countries and regions.
NOTE
Exceeding a total current consumption may result in damage. The USB 1.1 and USB
2.0 devices maximum current consumption are 500mA. The USB 3.0 device maximum
current consumption is 1A (only for some models).
For individual non-standard high-capacity mobile hard disk, if its impulse current is
greater than or equal 1A, it may cause TV-rebooting or self-locking. So the TV does not
support it.
DIGITAL
AUDIO OUT
AV IN
White(L)
Red(R)
Yellow(Video)
(not included)
(not included)
(not included)
VCR/DVD Player/
Recorder/Set-top box/
Satellite Receiver/
Video Camera
Video
L
A/V OUT
R
To Next Page
