5
Attach the Wall Mount Bracket (not included)
Before you begin the third-party manufacturer instructions, be
sure to do the following things:
1. Place the TV face down on a clean, safe and cushioned surface.
2. Remove the TV stand if you already attached it.
3. Place the spacers (not included) in the corresponding bracket
holes.
Screw
(not provided)
CAUTION:
• Whenyouattachthemount,besuretousethespacers
(provided by the third-party manufacturer) between the TV
and the bracket.
• TopreventinternaldamagetotheTVandensureitis
mountedsecurely,besure tousefixingscrews(not
provided) that are 8.0-10.0mm(43") / 9.5-11.5mm(50"/55"/65")
in length when measured from the attaching surface of the
mounting hook.
Rear cover of the TV Spacer
Screw
Wall mount bracket
8.0 - 10.0 mm(43")
9.5 - 11.5 mm(50"/55"/65")
Wall mount hole pattern
VESA (mm)
200 × 200 (43"/50")
300 × 200 (55")
400 × 200 (65")
Wall mount screw size (mm) M6
Follow instructions provided with the Wall mount bracket.
To complete the installation, please contact the wall-mount
manufacturer or the retailer from which you purchased the TV.
The selected screws are 8.0-10.0mm(43") / 9.5-
11.5mm(50"/55"/65") in length when measured from the
attaching surface of the rear cover.
NOTE: The diameter and length of the screws differ
depending on the Wall-mount bracket model.
Bracket
(not provided)
Spacer
(not provided)
