Hisense 43R6E4 User Manual

19
Product specifications
MODEL NAME
65R6E4 75R6E4
Dimension
(W x H x D)
Without
Stand
57.2 × 32.8 × 2.9 inches
(1452 × 834 × 74 mm)
66.0 × 38.0 × 3.3 inches
(1677 × 966 × 85 mm)
With Stand 57.2 × 35.3 × 11.5 inches
(1452 × 896 × 291 mm)
66.0 × 41.0 × 14.1 inches
(1677 × 1 041 × 357 mm)
Weight Without
Stand
36.4 lbs (16.5 kg) 57.3 lbs (26.0 kg)
With Stand 36.8 lbs (16.7 kg) 58.4 lbs (26.5 kg)
DISPLAY
Active Screen Size
(Diagonal)
64.5 inches 74.5 inches
Screen Resolution 3840×2160
Panel Selected UltraHighDenitionbacklight
POWER
Power Supply AC 120V, 60Hz
Standby Consumption Less than 0.5W
Audio Power 10W + 10W 12W + 12W
CHANNELS & SIGNALING
Receiving Channels VHF: 2 - 13, UHF: 14 - 69, CATV: 1 - 125
Digital Terrestrial Broadcast (8VSB): 2 - 69
Digital cable (64/256 QAM): 1 - 135
Tuner Type Frequency synthesized
Receiving System Analog: NTSC
Digital: ATSC/QAM
