5
TV Rear
TV Rear
COMMON
INTERFACE
HEADPHONE
HDMI
HDMI
SERVICE
USB
USB
USB
NOTES
Check the jacks for position and type before making any connections. Loose
connections can result in image or color problems. Make sure that all connections
are tight and secure.
The TV may not be compatible with all external devices. To check compatibility,
please refer to the user manual of external device.
Do not connect external equipment while TV's power cord is plugged in. It may
cause electric shock.
ANT
ARC
SERVICE
HEADPHONE
USB 3
DC 5V 1A(MAX)
DC 5V
0.5A(MAX)
USB 1
USB 2
HDMI 2(4K@60Hz)
MHL(DC 5V 900mA)
HDMI 1(4K@60Hz)
COMMON INTERFACE
CARD FACE FRONT
HDMI 3
(4K@30Hz)
HDMI 4
(4K@30Hz)
DIGITAL
AUDIO OUT
Y
VIDEO
P
B
L
P
R
R
AV IN
COMPONENT IN
ANT
LAN
Power Input
