3
Installing the Stand or Wall Mount Bracket
Wall-Mount hole pattern (mm) 800 × 400
Wall-Mount screw size M8
Installing the Wall Mount Bracket
NOTES
The diameter and length of the screws differ depending on the wall mount bracket
model.
Wall mount bracket is optional, your device may not have wall mount bracket, please
refer to the actual accessories.
9.5~11.5mm
Wall Mount Bracket
Wall Mount Screw
Wall Mount Spacer
Rear cover of the TV
Follow instructions provided with the wall mount bracket.
R1
L1
Stand
Cable clamp
Screws: M5 x 16
To Next Page
