A：The accumulated time of defrosting is longer than 12 minutes (EEPROM setting value in the current
operating mode);
B：If the temperature of coiled pipe is equal to or higher than 14 degrees centigrade (EEPROM setting value
in the current operating mode);
Actions of exiting the defrosting state:
The compressor stops, and 50 seconds later the four-way valve opens, and another 10 seconds later the
compressor and outdoor fan restart and begin normal operation.
6. Electrical Characteristics
6-1. Print Circuit Board (Indoor & Outdoor)
Model
Indoor unit Size
PCB
AS-09CR4SVDTD5
738
IU-PCB-1
AS-09CR4SVDDF5
738
IU-PCB-1
AS-09HR4SVDTD5
738
IU-PCB-1
AS-09HR4SVDTE5
738
IU-PCB-1
AS-12CR1FVDTD1
738
IU-PCB-1
AS-12CR4SVETE3
808
IU-PCB-1
AS-12CR4SVEDA3
808
IU-PCB-1
AS-12CR5FVDDA
738
IU-PCB-1
AS-12CR5FVETE1
808
IU-PCB-1
AS-12HR1FVDTD1
738
IU-PCB-1
AS-12HR4SVETD2
808
IU-PCB-1
AS-12HR4SVETE2
808
IU-PCB-1
AS-12HR5FVDDA
738
IU-PCB-1
AS-12HR5FVETE1
808
IU-PCB-1
AS-18CR4SXATE
908
IU-PCB-1
