6.3.3 Removing the PTC starter and overload protector
1.Unplug the appliance
2.Remove the screws of protector box by screwdriver,as picture 1.
3.Pry up the protector box from top by screwdriver,as picture 2.
4.Unplug the overload protector,as picture 3.
5.Unplug the PTC starter,as picture 4.
Picture1 Picture2
Picture3 Picture4
43
6.Circuit and checking
