47
6.5.3 Removing the damper
6.Circuit and checking
1.Unplug the appliance
2.Remove the screws of refrigerator wind channel component by
screwdriver,as picture 1.
3.Remove the wind channel component and unplug the terminals,as
picture 2.
4.Separate the wind channel cover and foam,as picture 3.
5.Remove the sponge and adhesive paper on the foam,as picture 4.
6.Separate the upper foam and lower foam,as picture5.
7.Remove the damper,as picture 6.
