1.After removing the freezer wind channel component,unplug the
terminals,as picture 1.
2.Remove the screws of evaporator by screwdriver,as picture 2.
3.Separate the evaporator component from the cabinet and remove
the foams at left side and right side,as picture 3.
4.Cut the self locking ties that fastening the heater by knife,as
picture 4.
5.Pry up the buckles that fastening the heater by screwdriver and
then remove the heater,as picture 5.
