Hisense FV105D4BC21 User Manual

Hot vapors can lead to the damage of
plastic parts.
Ethereal oils and organic solvents can
attack plastic parts, e.g. lemon juice or the
juice from an orange peel, butyric acid, or
cleansers that contain acetic acid. Do not
allow such substances to come into
contact with appliance parts.
Do not use any abrasive cleansers.
Clean the appliance and the interior
accessories with a cloth and lukewarm
water. Commercially available dish
washing detergents may also be used.
After cleaning, wipe with fresh water and
a clean dish cloth.
Accumulation of dust at the condenser
increases energy consumption; clean the
condenser at the back of the appliance
once a year with a soft brush or a vacuum
cleaner.(Only for the outside-condenser
product)
Check the water drain hole on the rear
wall of the refrigerator compartment.
Clear a blocked drain hole with the aid of
something like soft green peg, an be
careful not to create any damage to the
cabinet by sharp objects.
After everything is dry, the appliance back
into service.
them into the fresh food compartment
temporarily.
leave the door of the refrigerator open
until ice and frost dissolve thoroughly
and accumulate at the bottom of the
freezer chamber. Wipe out the water with
soft cloth.
In order to speed up the process of
defrosting, you may put a bowl of warm
water (about 50℃) into the freezer
chamber and scrape away the ice and
frost with a defrosting spatula. After
doing so, be sure to set the knob of the
temperature regulator to the original
position.
It is not advisable to heat the freezer
chamber directly with hot water or hair
dryer while defrosting to avoid
deformation of the inner case.
It is also not advisable to scrape off ice
and frost or separate foods from the
containers which have been congealed
together with the food with sharp tools or
wooden bars, so as not to damage the
inner casing or the surface of the
evaporator.
Defrosting
Defrosting in frozen food storage
compartment
Defrosting in the freezer chamber is
operated manually. Before defrosting,
take the foot out.
Tale the ice tray and drawers out or put
Notice! The appliance should be defrosted
at least once a month. During its usage, if
the door has been used in extreme
humidity, we advise the user to defrost
every two weeks.
Taking the appliance out of service
Empty the appliance
Pull out the power plug
Clean thoroughly (see section: Cleaning
and Care).
Leave the door open to prevent odours
Hisense Refrigerator
11

Hisense FV105D4BC21 Specifications

General

Door hinge	Right
Control type	Rotary
Product type	Upright freezer
Product color	Stainless steel
Housing material	Metal
Reversible doors	Yes
Appliance placement	Undercounter
Convertible freezer	No
Freezer number of shelves/baskets	3
Connected load	- W
Energy efficiency scale	A to G
Annual energy consumption	164 kWh
Noise level	40 dB
Star rating	4*
Climate class	N-T
Freezing capacity	10 kg/24h
Freezer net capacity	82 L
Freezer gross capacity	91 L
Freezer temperature (max)	43 °C
Freezer temperature (min)	16 °C
Automatic defrost (freezer)	-
Storage time during power failure	24 h
Package depth	597 mm
Package height	890 mm

Weight and Dimensions

Depth	575 mm
Width	555 mm
Height	845 mm
Weight	36000 g
