Hisense FV105D4BC21 User Manual

50-70mm
Daily use
Accessories 1)
For storing frozen food.
Maximum performance and safety are
guaranteed by maintaining the correct
indoor temperature for the class of unit
concerned, as specified on the rating plate.
This appliance performs well from N to T.
The appliance may not work properly if it is
left for a longer period at a temperature
above or below the indicated range.
Important! It is necessary to have good
ventilation around the freezer to allow for the
dissipation of heat.For this reason,sufficient
clear space should be available around the
appliance. It is advisable for there to be
50-70mm separating the back of the freezer
the wall at least 100mm of space on its
sides and a clear space in front to allow
doors to open 160
°.
Appliances must not be exposed to rain.
Sufficient air must be allowed to circulate
in the low rear section of the appliance, as
poor air circulation can affect performance.
Built-in appliances should be positioned
away from heat sources such as heaters
and direct sunlight.
The appliance should be level in order to
eliminate vibration. To make the appliance
level, it should be upright and both
adjusters should be in stable contact with
the floor. You can also adjust the level by
unscrewing the appropriate level
adjustment in the front (use your fingers or
a suitable spanner).
Leveling
Caution! Any electrical work required to
install this appliance should be carried out by
qualified or authorized personnel.
Warning! This appliance must be grounded.
The manufacturer declines any liability should
these safety measures not be observed.
Electrical connection
Freezer Drawer
For making ice and storing ice- cubes.
Ice tray
For freezing fresh food and storing frozen
and deep-frozen food for long periods of
time.
Freezer food compartment 2)
Thawing food 2)
In the freezer compartment
In a microwave oven
1) If the appliance contains related accessories
and functions.
2) If the appliance contains a freezer compartment.
At room temperature
In a conventional or convection oven
Food once thawed should be re-frozen
with the exception of special cases
Hisense Refrigerator
9
the
to
two

Hisense FV105D4BC21 Specifications

General

Door hinge	Right
Control type	Rotary
Product type	Upright freezer
Product color	Stainless steel
Housing material	Metal
Reversible doors	Yes
Appliance placement	Undercounter
Convertible freezer	No
Freezer number of shelves/baskets	3
Connected load	- W
Energy efficiency scale	A to G
Annual energy consumption	164 kWh
Noise level	40 dB
Star rating	4*
Climate class	N-T
Freezing capacity	10 kg/24h
Freezer net capacity	82 L
Freezer gross capacity	91 L
Freezer temperature (max)	43 °C
Freezer temperature (min)	16 °C
Automatic defrost (freezer)	-
Storage time during power failure	24 h
Package depth	597 mm
Package height	890 mm

Weight and Dimensions

Depth	575 mm
Width	555 mm
Height	845 mm
Weight	36000 g
