7.6.1 Registering name of group (Block)
1 Select “Name Setting” from the screen of “Menu”.
2 Select the target (block or group) to set the name.
3 Enter the group (block) name and touch “OK”.
The screen will return to “Name Setting” and entered name is stored.
4 Touch “OK ” on the screen of (2) to return to the screen of AC Monitor.
(1)
NOTE
Clean and wipe the display with dry and soft cloth.
For oil and fat on the touchscreen such as finger print marks, use diluted neutral detergent. Before cleaning, wring water out
to dry. After that, again wipe the display with dry and soft cloth.
Do not use benzene, thinner or surface active agent in order to protect the touchscreen and body from deformation or
deterioration.
•
•
•
(3)
(1) (2)
(2)
HYJM-S01H
