Installing your Freestanding Cooker
Electrical connection
IMPORTAN
T: Electrical connections must be carried out by a suitably qualified
person and in accordance with all relevant local building and installation
regulations.
Fitting on a Power Supply Cable
Connecting appropriate power supply terminal board/ connector bl
ock:
Using a screwdriver, pr
ize open tabs of the Terminal board cover.
Remove the wire clamp screw.
Fasten the wires beneath the corresponding screw heads, using
brass ‘link’ for single phase supply.
Fasten cable clamp and close the cover of the terminal board.
The ac power supply should be 220-240 V, 50/60 Hz.
Connecting the supply cable to the mains
Install an approved circuit breaker with a minimum contact opening of 3 mm,
between the appliance and the mains Distribution board .The circuit breaker
should be sized according to the load and should comply with current
regulations (the earth wire should not be interrupted by the circuit breaker).
The supply cable should be positioned so that it does not reach a temperature
of more than 50℃ with respect to the room temperature, anywhere along its
length. Before switching fuse ON in meter-box check:
Earth continuity. The electrical safety of this appliance can only be guaranteed
if the cooker is correctly installed and earthed, in compliance with regulations
on electrical installations.
The electrical capacity of the system and sockets will support the maximum
power of the appliance, as indicated on the data plate.
12
