Step-by-step installation guide
2.
INSTALLATION TYPES (Choose A, B or C)
This microwave oven is designed for adaptation to the following
three types of ventilation: A:Outside Top Exhaust(Vertical Duct)
B:Outside Back Exhaust(Horizontal Duct)
C:Recirculating(Non-Vented Ductless)
A. OUTSIDE TOP EXHAUST(Vertical Duct)
B . OUTSIDE BACK EXHAUST(Horizontal Duct)
C . RECIRCULATING(Non-vented Ductless)
See page 14
Adaptor in Place
for Outside Top
Exhaust
13
NOTE: This microwave is shipped assembled for Recirculating.
See page 18
See page 22
