3. Unscrew the flange screws ① which
are used for fixing the right upper hinge
part ②. Lift the upper door and place it
on a padded surface to prevent it from
scratching.
4. Remove the upper door and place it
on a smooth surface with its panel
upwards. Loose screws② , detach
part① , then install part① to the left
side with screws②.
Note: Please hold the upper door by hand
during step 3 to prevent door dropping.
6. Place the lower door on a smooth
surface with its panel upwards.Loose
screws②，detach part①. Then install
part①to corresponding position on left
side together with screws②.
5. Loose screws used to fix the middle
hinge and remove middle hinge. Then
remove the lower door.
Hisense Refrigerator
6
②right upper hinge part
①flange screws
8. Place refrigerator flatwise, remove
part③ and then loose screws④ .
Remove part ② and part①.
③Upper hinge cover (right)
②screw
①Screw cover
④Screw hole cover
1
② Self-tapping screws
① Stop block
①
②
7. Change screw hole covers on
middle cover plate from left to right (as
shown in figure below).
② self-tapping screws
① Door holder
1
2
①
②
