Hisense HRF266N6CSE Use & Care Guide

3.
1.
2.
3.
4.
Remove the 4 hex head bolts hinges (E)
with an Allen wrench (5/32",4mm).
Remove the lower left and right door
hinges (F).
Pull out the freezer door and the upper
freezer drawer (G) to the final position.
Take out the ice storage box (H) by
lifting it up in the direction of the arrow.
Take out the upper freezer drawer (G)
by lifting it up from the rail system.
Disassembling the freezer door
Use both hands to open the door more
than 90°. Lift it up and take it off.
G
G
H
F
E
6

Hisense HRF266N6CSE Specifications

General

Style	French Door
Color	Stainless Steel
Number of Doors	3
Total Capacity	25 cu. ft.
Refrigerator Capacity	13.9 cu. ft.
Freezer Capacity	5.5 cu. ft.
Number of Refrigerator Shelves	5 Total (4 Adjustable Half-Width; 1 Fixed Full-Width)
Number of Refrigerator Bins	4
Humidity Controlled Crispers	2 Half Crispers & 1 Full Width Pantry
Number of Freezer Shelves/Baskets	2 Drawers
Refrigerator Temperature	34° F to 47° F
(-14°C)	-
Refrigerator Special Features	LED Lighting
Freezer Special Features	Quick Freeze
Defrost System	-
Noise level	43 dB
Refrigerant	R600a
Energy Class	E
Annual Energy Consumption	628 kWh
Voltage	-
Frequency	-
Current	-

Weight and Dimensions

Depth	27 in
Height	72 1/2 in
Width	32 7/8 in
Net Weight	232.75 lbs
