Hisense HRF266N6CSE Use & Care Guide

4.You need to purchase several item to
compalet this connection.You may find
these items sold as a kit at local hardware
store.
Re-assembling the freezer door
To reattach the drawer after you moved
the appliance to its final location,
assemble the parts in reverse order.
A water dispenser with a filter is one of the
helpful features on your new appliance.
To help promote better health, the water
filter removes unwanted particles from your
water. However, it does not sterilize or
destroy microorganisms. You may need
to purchase a water purifying system to
do that.
In order for the ice maker to operate
properly, a water line is required.
-the maximum inlet water pressure is 700kPa;
-the minimum inlet water pressure is 207kPa.
Installing the water lines
Remove the lower freezer drawer (C)
by lifting it up.
Remove the 4 screws attached to the
supporting frame (D).
C
Pull out the freezer door and lift it upin
the direction of the arrow.
1. Power drill and 1/4’’ drill bit.
2. 1/2’’ or adjustable wrench.
3. Flatblade and Philips head screwdrivers.
D
1 ferrule
(sleeve)
What you need to have before you star
Saddle-type
Shut offvalve
(1/4” outlet)
one 1/4”
compression
1/4” extension
tubing
1 Coupler 2 Clips
4.
5.
6.
7
D
WARNING!
The water connection must be made
by a qualified plumber. Operation
outside the water pressure range
may cause malfunction, severe and
damaging water leaks.
Under normal conditions, a200cc
(5.75 oz.) cup can be filled in about
10 seconds.
If the refrigerator is installed in an area
with low water pressure (below 30psi),
you can install a booster pump to
compensate for the low pressure.

Hisense HRF266N6CSE Specifications

General

Style	French Door
Color	Stainless Steel
Number of Doors	3
Total Capacity	25 cu. ft.
Refrigerator Capacity	13.9 cu. ft.
Freezer Capacity	5.5 cu. ft.
Number of Refrigerator Shelves	5 Total (4 Adjustable Half-Width; 1 Fixed Full-Width)
Number of Refrigerator Bins	4
Humidity Controlled Crispers	2 Half Crispers & 1 Full Width Pantry
Number of Freezer Shelves/Baskets	2 Drawers
Refrigerator Temperature	34° F to 47° F
(-14°C)	-
Refrigerator Special Features	LED Lighting
Freezer Special Features	Quick Freeze
Defrost System	-
Noise level	43 dB
Refrigerant	R600a
Energy Class	E
Annual Energy Consumption	628 kWh
Voltage	-
Frequency	-
Current	-

Weight and Dimensions

Depth	27 in
Height	72 1/2 in
Width	32 7/8 in
Net Weight	232.75 lbs
