Installation & Operation Manual for Wireless Remote Control
Remote Control Mode:
HYE-W01
To ensure correct use of this remote control, please read this manual carefully
before use.
This manual should be read along with the installation manual for air conditioner.
Discrepancy of display will occur when:
1)
You press Sleep button while sleep function is unavailable in your indoor unit;
2) You press ECO button while power saving function is unavailable in your
indoor unit;
3)
You press Mute button while power mute function is unavailable in your indoor
unit;
4)
You press S.H. button while strong heati ng functi on is unavailabl e in your indoor
unit;
Discrepancy of display may occur when:
1)You press 3D/S. button while 3D/strong airflow function is unavailable in your
indoor unit;
2) You press Hor. button while horizontal airflow function is unavailable in your
indoor unit;
Discrepancy of display may occur when lower temperature limit is set when this
remote control is used along with wired remote
control with receiver due to
difference in indoor units.
Check th
e box after checking related items as shown below.
□ 1) The following parts are part of the wireless Remote Control, please
check them.
Name Quantity Use
Wireless remote control
1
For control of operation
No.7 battery
2
For power supply to remote
control
Remote control holder
1
For fixing of remote control
Screw (M4×16)
For fixing of remote control
holder
□ 1) Mount two No.7 batteries into the battery container in remote control.
(1) Pulling out the container cover.
(2) Mount battery in.
Pay attention to poles of batteries when mounting them!
Operation Instructions
1) Remove the batteries if the remote control is left idle for a long period.
2) Replace the batteries in pair.
3) After replacement, press Reset button before using the remote control.
Due to improvement to the product, this manual may be subject to modification
without prior notice.
