- 12 -
LCD TV Service Manual
Hisense Confidential
3.2 LCD26W57：
General Description：
V260B1- L02 is a 25.5” TFT Liquid Crystal Display module with 8-CCFL Backlight unit
and RSDS interface.
This module supports 1366 x 768 WXGA format and can display 16.2M colors
(6-bits+FRC colors).
General Features
Item Specification Unit
Active Area
575.769 (H) x 323.712
(V)
(26” diagonal) mm
Bezel Opening Area 580.8 (H) x 328.8 (V) mm
Driver Element a-si TFT active matrix
Pixel Number 1366 x R.G.B. x 768 pixel
Pixel Pitch (Sub Pixel) 0.1405 (H) x 0.4215 (V) mm
Pixel Arrangement RGB vertical stripe -
Display Colors 16.2M color
Display Operation
Mode
Transmissive mode / Normally White -
Surface Treatment Anti-Glare coating (Haze 25%) Hard coating (3H) -
3.3 LCD32W57
General Description：
V315B1-L01 is a 31.5” TFT Liquid Crystal Display module with 16-CCFL Backlight
unit and a ch LVDS interface.
This module supports 1366 x 768 WXGA format and can display 16.7M colors (8-bits
colors).The inverter module for backlight is built-in.
