LCD PANEL SPEC.
INNOVATION IS LIFE
INNOVATION IS LIFE
Active Screen Size 31.51 inches(80.04cm) diagonal
Outline Dimension 760(H) x 450(V) x 32(D) mm(Typ.)
Pixel Pitch 0.5107mm x 0. 5107mm x RGB
Pixel Format
1366 horiz. By 768 vert. Pixels RGB strip
arrangement
Color Depth 16.7M colors
Viewing
Angle(CR>10)
View Angle Free (R/L170(Typ.), U/D 170(Typ.))
Contrast Ratio 800
Supplying Voltage +5V
Power
Consumption
Total 110.4 Watt (Typ.)
Response Time 21ms
Luminance, White 500cd/m
2
Surface Treatment Hard coating 3H and Anti-glare
General Features
LCD3206EU/LCD3205EU: QD32HL01(QDI LCD PANEL)
