4. Chassis Layout and Overall Wiring Diagrams
Boards and Chassis Layout
LCD32V86：
No Description Part No. Type/Model PCB/ Model
(1)
Main board 120726 RSAG2.908.1497-7\ROH RSAG7.820.1637\VER.E\ROH
(2)
Power board 120822 RSAG2.908.1285-2\ROH RSAG7.820.1377\VER.B\ROH
(3)
Keypad PCA 120779 RSAG2.908.1573-3\ROH RSAG7.820.1755\VER.A\ROH
(4)
IR board 121198 RSAG2.908.1566-2\ROH 0RSAG7.820.1725\VER.C\ROH
LCD32V86P：
No Description Part No. Type/Model PCB/ Model
(1)
Main board 121184 RSGA2.908.1497-15\ROH RSAG7.820.1637\VER.E\ROH
(2)
Power board 120822 RSAG2.908.1285-2\ROH RSAG7.820.1377\VER.B\ROH
(3)
Keypad PCA 120779 RSAG2.908.1573-3\ROH 15RSAG7.820.1755\VER.A\ROH
(4)
IR board 121198 RSAG2.908.1566-2\ROH RSAG7.820.1725\VER.C\ROH
