NOTE
Features, appearance and specifications are subject to chang e without notice.
Dimension
With Base
Width: 36.7 inches(931.3 mm)
Height: 23.4 inches(595.2 mm)
Depth: 9.4 inches(240 mm)
Without Base
Width: 36.7 inches(931.3 mm)
Height: 21.7 inches(551.9 mm)
Depth: 2.8 inches(72 mm)
Weight
NET 17 lbs(7.7 kg)
GROSS 24.3 lbs(11 kg)
LCD Panel Minimum size (diagonal) 40 inches
Screen resolution 1920 × 1080
Audio power 8 W + 8 W
Power consumption Please refer to the rating label
Power supply 120 V 60 Hz
Receiving
systems
Analog
Digital
NTSC
ATSC
Environmental conditions
VIDEO INPUT
VGA Format
Up to 1920x1080@60Hz
Video System
PAL/NTSC
Video level 1.0 Vp-p +/-5%
480i, 480p, 720p, 1080i, 1080p
480i, 480p, 720p, 1080i, 1080p
VIDEO
COMPOMENT
HDMI
Temperature: 5°C-45°C
Humidity: 20%-80% RH
Atmospheric pressure: 86 kPa - 106 kPa
The remote control requires:
• Number of Batteries: 2
• Type : AAA
• Voltage: 1.5Vcc
27
