Hisense NT72671 - Page 14

- 14 -
37
GND
32
GND
36
P2P4N
33
X0B_9P
35
P2P4P
34
X0B_9N
34
GND
35
GND
33
P2P3N
36
X0B_10P
32
P2P3P
37
X0B_10N
31
GND
38
GND
30
P2P2N
39
X0B_11P
29
P2P2P
40
X0B_11N
28
GND
41
GND
27
P2P1N
42
X0B_12P
26
P2P1P
43
X0B_12N
25
GND
44
GND
24
P2P_LOCK
45
P2P_LOCK
23
GND
46
GND
22
MISO
47
SPI_PANEL_MISO
21
MOSI
48
SPI_PANEL_MOSI
20
SCLK
49
SPI_PANEL_CLK
19
CS
50
SPI_Demura_CS
18
GND
51
GND
17
NC
52
T_nWR
16
S_SCL
I2C_CLK
53
T_SCL
15
S_SDA
I2C_DATE
54
T_SDA
14
GND
Ground
55
GND
13
GND
Ground
56
GND
12
GND
Ground
57
GND
11
GND
Ground
58
GND
10
GND
Ground
59
GND
9
NC
No Connection
60
NC
8
VCC_PANEL
Power Supply Input
Voltage
61
12V-Panel
7
VCC_PANEL
Power Supply Input
Voltage
62
12V-Panel
6
VCC_PANEL
Power Supply Input
Voltage
63
12V-Panel
5
VCC_PANEL
Power Supply Input
Voltage
64
12V-Panel
4
VCC_PANEL
Power Supply Input
Voltage
65
12V-Panel
3
VCC_PANEL
Power Supply Input
Voltage
66
12V-Panel
2
VCC_PANEL
Power Supply Input
67
12V-Panel
