Hisense NT72671 - 2.3 Ties, clamps and tapes

- 15 -
Voltage
1
VCC_PANEL
Power Supply Input
Voltage
68
12V-Panel
XP7：Speaker jacket
Pin
definition
illustration
Wire color
1
L+
Left speaker positive wire
红
2
L-
Left speaker negative wire
白
3
R-
right speaker negative wire
白
4
R+
Right speaker positive wire
红
2.3 Ties,clamps and tapes:
to show the positions where ties and clamps and tapes should be, for checking after
servicing, Before disassemble the TV ,besure to take photes for the TV assembly example
for 50A683FEVS.
